Details
Category | Levelers, Precision Roller |
---|---|
Manufacturer | Automatic Feed |
Year | 2006 |
Stock # | 102219 |
Description
SPECIFICATIONS:
MFG: Automatic Feed Co., Napoleon, OH
Year: 2006
Work Rolls: 2.25" Diameter x 82.625" Roll Face
17 Work Rolls
Spiral Groove Intermediate Back ups
7 total flights of Cam type Back Ups -Up & Down
Motorized wedge design adjustment of the 5 center flights of Back Ups
Interchangeable Cassette Design(one Cassette included)
No motor is included. Unit originally had a 110kw(147.5HP), 1500 RPM,
280MD Frame, Motor
Brad Foote Gear Box: 147.35HP, 1500 RPM, 2.84:1 Ratio
15 Ton Joyce Ball Screw Jacks(Strength Capability may be able to be
increased with increased
Jack Tonnage)
Right to Left mode of operation.
Pass Height: 54"
Distance from Entry to Exit less exit pinch rolls: 59"
Valves, Graco Lube System & IOs are attached to the Leveler Frame.
We did not receive a PLC, HMI(Operators Controls)
Mild & HS Steels
There is one damaged work roll(AFCO replacement cost $ 2262.00) This
roll has been purchased through Automatic Feed Company & is included
in the sale.
Located at our Mack Ave., Detroit, MI Warehouse
Ship Weights:
Frame: 38,000lbs
Cassette: 18,000lbs
Gear Box: 6500lbs
