SPECIFICATIONS:

38.4 Pitch daim.
2.5 diametral pitch
20 degree pressure angle
96 teeth
44.66" bolt circle lower
40.94" bolt circle upper
5/8-11 bolt holes
3.54 height
47" diameter base frame diameter
1" ball diameter
42.81 bearing pitch diameter
119 aprox. # of balls
60 degree contact angle
0.0000 bearing IDC
Static Capacity:
 Axial(lbs) Moment(ft.lbs) Radial(lbs)
frequent static loading 362,709 258,793 83,764
intermittent heavy duty 544,046 388,177 125,642
theoretical stress limit 725,375 517,555 167,518
ABMA 1990 1,107,939 790,514 255,867
